SQRDPWB L102
Trench roller SQRDPWB L102
Compacts the trench floor, remote-control ready.
EngineHonda GX390 · 13 HP
Compare with another machineParts available for this machineBuy it from ConstruMarket in El Salvador
SIMAQ advantages
- Padfoot drums to compact trench floors in cohesive soils
- Front and rear sprinkler system
- Hydraulic front-drum steering and integrated control lever
- Lifting point for safe moving on site
Features
- Padfoot
- Articulated
Specifications
- Drum width
- 680 mm
- Centrifugal force
- 17 kN
- Speed
- 0-3.5 km/h
- Weight
- 0.78 t
- Compaction frequency
- 65 Hz
SIMAQ on the job
Proven on the real jobsite
Compacts the trench floor, remote-control ready.
5-minute training
5 minHow to use the walk-behind trench roller
Walk-behind double-drum padfoot roller: compacts the trench floor in cohesive soil, guided by the handle (no remote control).
Get your operator certified for free (Spanish)- 01
Check and refill
Engine and hydraulic oil, fuel and water. Padfoot lugs free of packed-in material between them.
- 02
Start with vibration off
Position the machine, bring the engine to full throttle, and only then engage vibration (it won't kick in at low rpm). Guide with the handle, don't force it.
- 03
Lifts and passes
20–30 cm lifts, 4–6 overlapping passes. The padfoot kneads cohesive soil from the bottom up.
- 04
Use the articulated joint
The articulated joint steers around covers and obstacles without tearing up fresh work. Smooth turns from the handle.
- 05
Mind your position in the trench
Keep your body behind the handle, never between the machine and the trench wall. Check slope and shoring before going in.
Do this
- Go to full throttle before engaging vibration.
- Keep your body behind the handle at all times.
- Clean the padfoot lugs at the end of the shift.
Avoid this
- Don't stand between the machine and the trench wall.
- Don't use it as a finish smooth roller: it leaves lug marks.
- Don't operate with the trench shoring in poor condition.
Safety
- Hard hat, boots, gloves, glasses and hearing protection.
- Mind your feet and the handle pinch point on turns.
- Slope and shoring checked before any maneuver.
Calculate before you quote
Applications
What jobs this machine is built for.
- Road bases and sub-bases
- Trench and pipe backfill
- Paving and interlock
- Embankments and pads
- Asphalt finishing
Where this machine earns its keep
The same machine, told for your business: pick your industry and see the full case.
Buying guides
Clear up your questions before you quote
Guide · 7 min
How to choose the right compactor for your soil type
Granular or cohesive, base or trench: the rule is simple — the soil decides. A quick guide so you don't over-buy or redo the work.
Read Guide · 7 minWhich roller compactor should you choose by tonnage and job?
From 0.78 to 4.2 tonnes: the seven SIMAQ rollers side by side, with weight, drum width, force and engine, and which roller compactor fits sidewalks, trenches, streets or roadwork.
Read Guide · 6 minWhat is a jumping jack rammer and when should you use it?
The rammer compacts by impact: narrow trenches, next to pipe and walls, and clay soils. How to use it, when not to, and the SIMAQ SQ60 PRO 2.
ReadFrequently asked
Which compactor do I need for my soil?
Vibratory plate for granular soil, pavers and open areas; rammer (jumping-jack) for trenches and cohesive soils; roller for large areas and asphalt. Tell us the job and we'll recommend the machine.
Diesel, gasoline or electric?
Gasoline (Honda) for general, portable use; diesel for heavy duty and rollers; electric where emissions aren't allowed. All run world-brand engines.
Does it include warranty and parts?
Yes: 6-month SIMAQ warranty, parts and local after-sales at every distributor (ConstruMarket — CMARKET in Guatemala).
How do I get a quote?
Through the form or WhatsApp — reply during business hours. For volume, request a wholesale / container quote.
