Official factory breakdown

Parts for SQ 140X PRO

425 parts for the Scissor lift SQ 140X PRO, with SIMAQ code, quantity per machine and spec where the manual provides it.

Parts
425
Wear items
37
Manual
SQ140XPROOM-2026-A
Order via WhatsAppFull manual (PDF)See the machine
Scissor lift SQ 140X PRO

Exploded diagram

The number on the drawing is the same # in the table.

425 parts in the official breakdown.

SIMAQ codePartQtySpecOrder
#1Bolt M10×202—Order
#2Spring washer 102—Order
#3Empaque/Gasket2—Order
#4Steering linkage1—Order
#5Pin1—Order
#6Plain washer 162—Order
#7Split Pin3.2×402—Order
#8Steering cylinder1—Order
#9Pin1—Order
#10Steering bracket1—Order
#11Hydraulic motor2—Order
#12Bolt M12×908—Order
#13Split Pin 4×502—Order
#14Steering bracket1—Order
#15Plain washer 128—Order
#16Hexagon nutM128—Order
#17Neumático/Tire2—Order
#18Flanging bushing2—Order
#19Pipe clamp2—Order
#20Bolt M8×801—Order
#21Hexagon nutM81—Order
#22Copper bush2—Order
#23Fibre bushing4—Order
#24Silenciador /Stifle2—Order
#25Screw M5×122—Order
#26Screw M10×352—Order
#27Hexagon nutM102—Order
#32Cylinder seal package1—Order
#1Bushing2—Order
#2Pin2—Order
#3Split Pin 3.2×404—Order
#4Pin2—Order
#5Junction plate2—Order
#6Bushing4—Order
#7Pin2—Order
#8Bolt M8×508—Order
#9Bushing3—Order
#10Roller2—Order
#11Clamp spring 203—Order
#12Bolt M6×164—Order
#13Spring washer 64—Order
#14Plain washer 64—Order
#15Pin4—Order
#16Flanging bushing4—Order
#17Anti-overturning plate A1—Order
#18Plain washer 164—Order
#19Hexagon nut M122—Order
#20Plain washer 122—Order
#21Anti-overturning plate B1—Order
#22Washer4—Order
#23Spring4—Order
#24Bolt M8×50 8——Order
#25Plain washer 8 20——Order
#26Curved plate 2——Order
#27Dust cover 1——Order
#28Vertical shaft 1——Order
#29Spring 1——Order
#30Fixed sleeve 1——Order
#31Spring washer 8 4——Order
#32Bolt M8×25 4——Order
#33Spring pin 5×16 2——Order
#34Oscillating rod 1——Order
#35Roller 3——Order
#36Washer 4——Order
#37Hexagon nut M8 4——Order
#38Bolt M12×90 2——Order
#39Plain washer 12 2——Order
#1Handle1—Order
#2Bolt M6×202—Order
#3Spring washer66—Order
#4Plain washer 66—Order
#5Lock body1—Order
#6Bisagra de batería/Battery door1—Order
#7Organic glass1—Order
#8Battery(12V)4—Order
#9Placa divisoria/Clapboard1—Order
#10Caucho/Rubber2—Order
#11Screw M8×122—Order
#12Spring washer 82—Order
#13Hexagon nut M82—Order
#14Power switch1—Order
#15Plain washer 242—Order
#16Flanging bushing2—Order
#17Pin 4×502—Order
#18Pin2—Order
#19Charger1—Order
#20Screw M6×204—Order
#21Screw M5×122—Order
#22Spring washer 52—Order
#23Plain washer 52—Order
#24Enchufe/plug1—Order
#25Protective ring1—Order
#1Oil pump1—Order
#2Bolt2—Order
#3Motor1—Order
#4Spring washer 814—Order
#54 - 20×3/4/Bolt 1/4 - 20×3/44—Order
#64/Plain washer 1/44—Order
#7Install panel1—Order
#8Bolt M8×256—Order
#9Plain washer 86—Order
#10Bolt M8×204—Order
#11Plain washer 84—Order
#12Buzzer1—Order
#13Bolt M4×122—Order
#14Spring washer42—Order
#15Plain washer42—Order
#16Bocina/Horn1—Order
#17Controller1—Order
#18Bolt M6×164—Order
#19Spring washer66—Order
#20Plain washer66—Order
#21Bracket1—Order
#22Contactor1—Order
#23Screw M6×10——Order
#24Bolt M6×202—Order
#25Lock body1—Order
#26Handle1—Order
#27Tank1—Order
#28Bracket1—Order
#29Filter1—Order
#30Valve bank1—Order
#31Plain washer104—Order
#32Spring washer104—Order
#33Bolt M10×252—Order
#34Plain washer 242—Order
#35Flanging bushing2—Order
#36Split pin 4×502—Order
#37Pin2—Order
#38Tank door1—Order
#39Bolt M10×202—Order
#40Bolt M6×204—Order
#41Hexagon nut M64—Order
#42Control panel1—Order
#1Tire2—Order
#2Bolt M12×908—Order
#3Split pin 4×502—Order
#4Hydraulic brake2—Order
#5Plain washer 128—Order
#6Hexagon nut M128—Order
#7Electrostatic belt1—Order
#8Bolt M6×201—Order
#9Plain washer 69—Order
#10Spring washer 69—Order
#11Bolt M6×164—Order
#12Bolt M12×304—Order
#13Cover plate1—Order
#14Boarding pedal1—Order
#15Bolt M8×702—Order
#16Plain washer 84—Order
#17Hexagon nut M82—Order
#18Brake release valve1—Order
#19Balancing weight2—Order
#20Plain washer 202—Order
#21Spring washer 202—Order
#22Bolt M20×2002—Order
#23Charger1—Order
#24Bolt M6×204—Order
#1Bastidor/Frame1—Order
#2Alarm lamp1—Order
#3Switch cover1—Order
#4Bolt M5×1616—Order
#5Plain washer 516—Order
#6Spring washer 516—Order
#7Bracket B1—Order
#8Bolt M4×354—Order
#9Spring washer 46—Order
#10Plain washer 410—Order
#11Limit switch2—Order
#12Bracket A1—Order
#13Limit switch2—Order
#14Tilt sensor1—Order
#15Bolt M4×122—Order
#16Bolt M10×304—Order
#17Hook2—Order
#18Hexagon nut M104—Order
#19Screw M6×168—Order
#20Spring washer 68—Order
#21Plain washer 68—Order
#22Cover plate2—Order
#1Tank body1—Order
#2Return pipe assembly1—Order
#3Breathing cover1—Order
#4Tank cap1—Order
#5Junta/Gasket1—Order
#6Filter1—Order
#7Suction joint1—Order
#8Plug1—Order
#1Screw M8×252—Order
#2Nylon pad1—Order
#3Adjusting shim2—Order
#4Spacer sleeve1—Order
#5Slider2—Order
#6Pin2—Order
#7Spacer sleeve2—Order
#8Bottom external frame1—Order
#9Internal frame A1—Order
#10External frame 14—Order
#11Internal frame B1—Order
#12Clamp spring 3822—Order
#13Thick gasket20—Order
#14Fibre bushing46—Order
#15Internal frame C1—Order
#16Pin5—Order
#17Internal frame D1—Order
#18Hexagon nut M1030—Order
#19Rubber40—Order
#20Maintenance arm4—Order
#21Plastic ring4—Order
#22Screw M10×304—Order
#23Internal frame E1—Order
#24Stop collar7—Order
#25Wiring channel B2—Order
#26Top external frame1—Order
#27Internal frame F1—Order
Internal frame F1—Order
#28Screw M10×7522—Order
#29Pin12—Order
#30Slider4—Order
#31Screw M10×1004—Order
#32Pin4—Order
#33External frame 21—Order
#34Pin4—Order
#35Pin3—Order
#36External frame 33—Order
#37Upper lifting cylinder1—Order
#38Pin3—Order
#39Wiring channel A3—Order
#40Screw M6×167—Order
#41Lifting cylinder1—Order
#42Pin1—Order
#43Bolt M8×302—Order
#44Pin2—Order
#45Angle sensor1—Order
#46Bolt M4×122—Order
#47Spring washer 42—Order
#48Plain washer 42—Order
#1Fixed platform1—Order
#2Clamp spring 472—Order
#3Bearing6204 - Z2—Order
#4Roller2—Order
#5Roller bracket2—Order
#6Screw M10×458—Order
#7Left guardrail2—Order
#8Spring Hinge2—Order
#9Bolt M6×5012—Order
#10Hexagon nut M612—Order
#11Rear guardrail1—Order
#12Entrance door1—Order
#13Rubber pad2—Order
#14Bolt M5×162—Order
#15Hexagon nut M52—Order
#16Spring1—Order
#17Plastic pin1—Order
#18Bolt M10×551—Order
#19Hexagon nut M101—Order
#20D-latch2—Order
#21Bolt M8×606—Order
#22Hexagon nut M86—Order
#23Fixed plate1—Order
#24Screw M5×122—Order
#25Plain washer 52—Order
#26Spring washer 52—Order
#1Extension platform1—Order
#2Screw M10×458—Order
#3Roller bracket2—Order
#4Roller2—Order
#5Bearing6204 - Z2—Order
#6Clamp spring 472—Order
#7Bolt M8×202—Order
#8Platform pedal1—Order
#9Right guardrail1—Order
#10Front guardrail1—Order
#11Bolt M6×164—Order
#12Spring washer 64—Order
#13Plain washer 68—Order
#14Handle bracket1—Order
#15Control handle1—Order
#16File box1—Order
#17Bolt M6×164—Order
#18Hexagon nut M64—Order
#19D-latch2—Order
#20Left guardrail1—Order
#21Rubber pad4—Order
#22Rivet 4×164—Order
#23Bolt M8×606—Order
#24Hexagon nut M86—Order
#1Pin1—Order
#2Spring1—Order
#3Pedestal——Order
#4Guide sleeve1—Order
#5Pedal1—Order
#6Plain washer 103—Order
#7Hexagon nut M102—Order
#8Bolt M10×501—Order
#12 - M24/Connector G1/2 - M241—Order
#22 - M20/Connector G1/2 - M205—Order
#3Connector M204—Order
#48 - M20/Connector G3/8 - M209—Order
#5Connector M22 - M202—Order
#64 - M16/Connector G1/4- M165—Order
#716 - M16/Connector G7/16- M165—Order
#8Connector M162—Order
#9Connector2—Order
#10Air pipe1—Order
#11Rubber pipe1—Order
#12Rubber pipe1—Order
#13Rubber pipe1—Order
#14Rubber pipe1—Order
#15Rubber pipe1—Order
#16Rubber pipe1—Order
#17Rubber pipe1—Order
#18Rubber pipe2—Order
#19Rubber pipe4—Order
#20Rubber pipe1—Order
#21Connector M241—Order
#22Connector M201—Order
#23Rubber pipe1—Order
#24Connector 1——Order
#25Air pipe 1——Order
#26Air pipe 1——Order
#1Lifting cylinder1—Order
#2Digging rope1—Order
#3Lower cylinder valve1—Order
#3-1Bracket1—Order
#3-2Solenoid coil1—Order
#3-3Valve element1—Order
#3-4Damping plug1—Order
#3-5Check valves1—Order
#4Screw M8×604—Order
#5Spring washer 84—Order
#6Pressure sensor block1—Order
#7Cylinder seal package1—Order
#1Lifting cylinder1—Order
#2Upper cylinder valve1—Order
#2-1Solenoid coil1—Order
#2-2Valve element1—Order
#3Screw M8×554—Order
Spring washer 8——Order
Cylinder seal package——Order
#1Relief valve1—Order
#2Relief valve1—Order
#3Relief valve1—Order
#4Solenoid directional valve1—Order
#5Solenoid directional valve1—Order
#6Solenoid directional valve1—Order
#7Solenoid directional valve1—Order
#8Solenoid Coil4—Order
#9Solenoid Coil2—Order
#10Flow valve1—Order
#11Check valve1—Order
#12Check valve2—Order
#13Check valve1—Order
#14Orifice1—Order
#1Main harness1—Order
#2Switch harness1—Order
#3Angle sensor harness1—Order
#4Pressure sensor harness1—Order
#5Cable1—Order
#6Cable1—Order
#7Cable1—Order
#8Cable1—Order
#9Handle cable1—Order
#10Cable1—Order
#11Cable2—Order
#12Cable2—Order
#13Charger wire1—Order
#1Control handle1—Order
#2Panel4—Order
#3Panel sticker1—Order
#4Handle body1—Order
#5Emergency stopswitch1—Order
#6Cover plate1—Order
#7Buzzer1—Order
#8Spiral wire1—Order
#1Bolt M6×162—Order
#2Spring washer6—Order
#3Plain washer 62—Order
#4Control panel1—Order
Control panel1—Order
#5Control module1—Order
#6Panel sticker1—Order
#7Chain1—Order
#8Key switch1—Order
#9Interruptor de paro de emergencia1—Order
#10Panel——Order
#1Rated load2—Order
#2Operation instruction2—Order
#3Safe distance1—Order
#4Overload tipping hazard1—Order
#5Tilt alarm operation1—Order
#6Tipping hazard1—Order
#7Save the manual1—Order
#8Brake release Instructions1—Order
#9Emergency descentinstruction1—Order
#10Forklift position2—Order
#11Binding position4—Order
#12Lifting hole4—Order
#13MAX. manual force1—Order
#14Anti collision warning2—Order
#15Trademark2—Order
#16Reflective stripe4—Order
#17Away from moving parts2—Order
#18Anti-pinch hand4—Order
#19Tire change warning4—Order
#20Parking warning label2—Order
#21Tire load4—Order
#22Electricity safety label1—Order
#23Mains switch1—Order
#24Press foot warning2—Order
#25Open the door and fli2—Order
#26Maintenance instruction lab2—Order
#27Explosion and fire risk1—Order
#28Battery change Warning1—Order
#29Maintenance instruction4—Order
#30Model number2—Order
#31Safety belt hook4—Order
#32Trademark1—Order
#33IPAF symbol1—Order
#34CE symbol1—Order
#35Prohibited to change the1—Order
#36Nameplate1—Order
#37Rivet 4×124—Order
#38Waterproof warning1—Order
#39Hydraulic sputtering hazard1—Order

Breakdowns in the same family

Category: Material Handling · All breakdowns

WhatsAppGet a quote
