Official factory breakdown

Parts for SQTLK 6000

91 parts for the Light tower SQTLK 6000, with SIMAQ code, quantity per machine and spec where the manual provides it.

Parts
91
Wear items
5
Manual
SQTLK6KUB-2026-A
Order via WhatsAppFull manual (PDF)See the machine
Light tower SQTLK 6000

Exploded diagram

The number on the drawing is the same # in the table.

91 parts in the official breakdown.

SIMAQ codePartQtySpecOrder
#1Chassis assembly TLK6000 - Chassis1—Order
#2TLK6000 - Box1—Order
#3Tow truck TLK60001—Order
Conjunto de poste de iluminación TLK6000 - 9- 41—Order
#5KDW10031—Order
#6TLK6000 - Muffler1—Order
#7DSE - 31101—Order
#1TLK6000 - Fuel tank1—Order
#2Battery 60AH1—Order
#3Mudguard TLK60002—Order
#4Supporting bar TLK60004—Order
#5Outrigger jack TLK60004—Order
#6Large size1—Order
#7Door bolt TLK60002—Order
#8Spring cotter L138mm4—Order
#10Spring cotter MT3120Z- M16L3—Order
#11Guide wheel fit TLK60008—Order
#12Rectifier BAMH1000 - CWA/220V/60HZ4—Order
#13Capacitor TLK60004—Order
#14Rectifier shield 1 TLK60001—Order
#15Rectifier shield 2 TLK60002—Order
#16Trailer tail light TLK60002—Order
#17Drain outlet M81—Order
#18Oil drainage M161—Order
#19Fuel tank TLK60001—Order
#20Liquid level sensor MG- 1601—Order
#21Tank filler cap EF4 - 501—Order
#22TLK60001—Order
#23Check valve G1/21—Order
#24Tank plug G1/21—Order
#25The tower tip G1/2- 82—Order
#26The tower tip G1/2- 101—Order
#1Door 1 TLK6000+1 machine1—Order
#2Door 2 TLK6000+1 machine1—Order
#3Front shell TLK6000+1 machine1—Order
#4Rear shell TLK6000+1 machine1—Order
#5Top cover TLK6000+1 machine1—Order
#6Closure plate TLK6000+1 machine2—Order
#7Door lock TLK6000+1 machine2—Order
#8Hinge TLK6000+1 machine4—Order
#9Pneumatic pusher 450mm - 420N+1 machine4—Order
#10Cover DPK - 1+1 machine1—Order
#11Overflow kettle Small+1 machine1—Order
#12LED light DC12V+1 machine1—Order
TLK6000——Order
TLK6000——Order
TLK6000——Order
TLK6000——Order
TLK6000——Order
TLK6000——Order
TLK6000——Order
TLK6000——Order
#9Halogen lamp TG10004—Order
#10Hand winch 1T1—Order
#11Spiral cable 10- 1.5- 9- 65MM1—Order
#12Electric putter - SLA06 12V- 300KG1—Order
#13Junction box AG- 15201—Order
#14Lifting lug M222—Order
#15Spirit level T-shaped2—Order
#16Handle M10*1002—Order
#17Pulley - 1 6204+78U2—Order
#18Pulley - 2 6020+55U4—Order
#19Round shim - 1 T932—Order
#20Round shim - 2 T660—Order
#1Engine KDW10031—Order
#2Alternator LSA 40 VS11—Order
#3Radiator KDW10031—Order
#4Air filter V22031—Order
#5TLK6000——Order
6 100kg——Order
#7KDW1003——Order
#8KDW1003——Order
#9KDW1003——Order
#1Silencer TLK60001—Order
#2TLK6000——Order
#1Control cabinet unit TLK60001—Order
#2Instrument panel unit TLK60001—Order
#3Control cabinet door TLK60001—Order
#4Breaker panel TLK60001—Order
#5CMOD (control module) DSE - 31101—Order
#6Emergency stop XB2 - BS5421—Order
#7Bajada/Up/down button TLK60001—Order
#8Rotary switch -1 YJ139- LA391—Order
#9Rotary switch - 2 YJ139- XB2 - 11Y/211—Order
#11Miniature circuit breaker DZ47S 1P C 16A1—Order
#12Miniature circuit breaker DZ47S 1P C 6A4—Order
#13Hinge - 1 CL1042—Order
#14Hinge - 2 TLK60002—Order
#15NEMA outlet 20A1—Order
#16Water proof Box CF - 04081—Order
#17Magnetic sheet TLK60002—Order
