Parts for NIGHTMASTER 350LED

77 parts for the Light tower NIGHTMASTER 350LED, with SIMAQ code, quantity per machine and spec where the manual provides it.

Parts
77
Wear items
9
Manual
NIGHTMASTER350-2026-A
Order via WhatsAppFull manual (PDF)See the machine
Light tower NIGHTMASTER 350LED

Exploded diagram

The number on the drawing is the same # in the table.

77 parts in the official breakdown.

SIMAQ codePartQtySpecOrder
#1Chassis assembly1—Order
#2Box, canopy assembly1—Order
#3Tow truck1—Order
#4Light pole assembly1—Order
#5Power pack assembly1—Order
#6Exhaust system assembly1—Order
#7Control system assembly1—Order
#1Fuel tank assembly1—Order
#2Battery1—Order
#3Mudguard2—Order
#4Supporting bar2—Order
#5Outrigger jack3—Order
#6Battery negative switch1—Order
#7Door bolt2—Order
#8Spring cotter2—Order
#9Trailer tail light2—Order
#10Drain outlet1—Order
#11Oil drainage2—Order
#12Fuel tank1—Order
#13Liquid level sensor1—Order
#14Tank filler cap1—Order
#15Fuel pickup pipe1—Order
#16Check valve1—Order
#17The tower tip2—Order
#18Tank plug1—Order
#1Door 1 TLK6000+1 machine1—Order
#2Door 2 TLK6000+1 machine1—Order
#3Front shell TLK6000+1 machine1—Order
#4Rear shell TLK6000+1 machine1—Order
#5Top cover TLK6000+1 machine1—Order
#6Closure plate TLK6000+1 machine2—Order
#7Door lock TLK6000+1 machine2—Order
#8Hinge TLK6000+1 machine4—Order
#9Pneumatic pusher 450mm - 420N+1 machine4—Order
#10Cover DPK - 1+1 machine1—Order
#11Overflow kettle Small+1 machine1—Order
#12LED light DC12V+1 machine1—Order
#1Section 1 lighting components1—Order
#2Section 2 lighting components1—Order
#3Section 3 lighting components1—Order
#4Section 4 lighting components1—Order
#5Section 5 lighting components1—Order
#6Light fixture mounting bracket1—Order
#7LED light4—Order
#8Hand winch1—Order
#9Spiral cable1—Order
#10Electric putter - SLA061—Order
#11Junction box1—Order
#12Handle2—Order
#13Square handle2—Order
#14Pulley5—Order
#15Round shim60—Order
#16Section 1 bar steel rope1—Order
#17Section 2 bar steel rope1—Order
#18Section 3 bar steel rope1—Order
#19Section 4 bar steel rope1—Order
#1Engine1—Order
#2Alternator1—Order
#3Radiator1—Order
#4Air filter1—Order
#5Air filter bracket1—Order
#6Damping pad4—Order
#7Upper radiator hose1—Order
#8Lower radiator hose1—Order
#9Air intake hose1—Order
#1Silencer1—Order
#2Silencer connecting pipe1—Order
#1Control cabinet unit1—Order
#2Instrument panel unit1—Order
#3CMOD (control module)1—Order
#4Rotary switch -11—Order
#5Bajada/Up/down button1—Order
#6Rotary switch -22—Order
#7Residual current operated circuit breaker1—Order
#8Miniature circuit breaker1—Order
#9Miniature circuit breaker4—Order
#10Hinge2—Order
